The Storz Medical D-ACTOR 100 (MASTERPULS MP100)
- Just Healthy
- 3 days ago
- 7 min read
Commanding a sector that holds nearly 58% of the global market, the Storz Medical D-ACTOR 100 delivers high-precision ballistic power in a portable unit, effectively treating both chronic orthopedic conditions and aesthetic concerns.
Key Takeaways
Delivers stationary-grade power in a mobile package. Don't let the size fool you. The MP100 uses ballistic pneumatic technology to generate 5.0 bar of pressure. It matches the intensity of the larger MP200 tower units but weighs only 10.5 kg.
Maximizes ROI through dual functionality. One machine handles two revenue streams. You can treat orthopedic injuries like plantar fasciitis and switch immediately to aesthetic procedures like cellulite reduction. This versatility makes it a financial powerhouse for multidisciplinary clinics.
Eliminates clutter with a self-contained design. The device solves the logistical headaches of older systems. An integrated silent compressor replaces noisy external air boxes and messy hoses, creating a clean workspace that is easy to transport between rooms.
Why the Market Chooses the Storz Medical D-ACTOR 100
The market for non-invasive pain and aesthetic treatments is growing faster than ever. In fact, recent data shows that radial pressure wave devices now make up nearly 58% of the total shockwave therapy market.
This massive popularity comes down to one simple reason: versatility. Clinics want machines that can handle everything from a runner’s injured heel to aesthetic body contouring.
This brings us to the Storz Medical D-ACTOR 100, which you will also see sold as the MASTERPULS MP100 ultra. It is one of the most well-known machines in this growing field.
Technically, this device creates radial acoustic waves using ballistic pneumatic technology. That might sound complex, but the idea is actually quite simple.
The machine uses compressed air to fire a small projectile inside the handpiece. When this projectile hits the transmitter tip, it creates energy waves that travel into the patient's tissue.
Translating this mechanism into clinical practice, the D-ACTOR 100 offers a distinct set of operational advantages. Below is a detailed analysis of its specifications and performance capabilities.
Technical Deep Dive
While many shockwave devices look similar on the outside, the D-ACTOR 100 sets itself apart by packing a 5.0 bar ballistic pneumatic system into a compact frame, defining its superior reliability and clinical performance.
How It Works
Unlike electromagnetic systems, such as the DUOLITH SD1 T-TOP 'ultra' which use coils and magnets, this machine uses ballistic pneumatic technology. Think of it as a tiny, high-precision jackhammer.
The Process: A built-in compressor creates air pressure. This air launches a small projectile (like a bullet) inside the handpiece tube.
The Impact: The projectile hits the metal transmitter tip at high speed.
The Result: This collision creates a kinetic energy wave that travels into the patient's tissue.
Why it matters: This mechanical method is famous for creating strong, broad energy waves that are excellent for breaking down scar tissue and treating larger muscle groups.
Performance Specs
The D-ACTOR 100 pairs a broad intensity range with high-speed precision, ensuring it performs exceptionally well across both delicate aesthetic work and deep orthopedic treatments.
It offers fully adjustable pressure from a gentle 0.3 bar up to a powerful 5.0 bar, alongside shockwave frequencies ranging from 1 Hz to 21 Hz.
For muscle relaxation, the system also supports the V-ACTOR handpiece, which reaches vibration speeds of 35 Hz or up to 50 Hz with the newer HF models.
Portability Factor
One of the biggest selling points of the D-ACTOR 100 is its fully integrated design, meaning the silent air compressor is built directly into the unit rather than sitting separately on the floor.
Air Power: It has a built-in silent compressor. You don't need a separate, noisy air box sitting on the floor.
Weight: At roughly 10.5 kg (23 lbs), it is light enough to move between treatment rooms or even take to sports events.
Clean Setup: Because everything is built-in, you don't have messy external hoses cluttering your workspace.
What Can You Treat?
The true strength of the D-ACTOR 100 lies in its multidisciplinary versatility.
Because it offers such a broad frequency range, you can treat a high-performance athlete for a sports injury at 9:00 AM and a patient seeking aesthetic body contouring at 9:30 AM without changing machines.
Orthopedics & Pain Management
For musculoskeletal issues, the device excels at treating chronic tendon and muscle disorders:
Plantar Fasciitis: Heel pain and chronic inflammation.
Achilles Tendinopathy: Pain and thickening of the Achilles tendon.
Epicondylitis: Tennis Elbow and Golfer’s Elbow.
Calcific Tendinitis: Breaking down calcium deposits in shoulder tendons.
Patellar Tendinitis: Treating Jumper’s Knee.
Tibial Stress Syndrome: Relieving shin splints.
Myofascial Trigger Points: Releasing deep muscle knots in the back, shoulders, and neck.
Arthritis: Helps manage pain associated with arthritis (specifically Osteoarthritis).
Wrist Pain: Effective for Carpal Tunnel Syndrome.
Aesthetics & Body Contouring
Using Acoustic Wave Therapy (AWT), the MP100 is also a fully capable aesthetic device:
Cellulite Reduction: Smoothes dimpled skin (Stages I–III).
Body Contouring: Improves overall silhouette and firmness.
Skin Tightening: Increases elasticity in loose or sagging skin.
Stretch Marks (Striae): Improves the appearance of pregnancy or growth marks.
Lymphatic Drainage: Reduces fluid retention and swelling.
Scar Tissue: Smoothes surface scars and improves skin texture.
MP100 vs. MP200
If you are shopping around, you will likely see the D-ACTOR 200 (MP200) mentioned alongside the MP100.
It is important to know that both machines offer the same power (up to 5.0 bar), but they are built for different environments.
Feature | MP100 Ultra | MP200 Ultra |
Nickname | The Compact Workhorse | The Big Brother |
Weight | ~10.5 kg (Easy to move) | ~23 kg (Stationary) |
Handpiece Ports | 1 Port | 2 Ports (Connect two tools at once) |
Vacuum Therapy | Not Supported | Supported (VACU-ACTOR) |
Best For | Portability & Efficiency | Multi-room Clinics & Complex Therapy |
Unless you specifically need vacuum cupping therapy for lymphatic drainage, the MP100 handles all the same orthopedic and aesthetic conditions as the larger MP200.
Storz Medical D-ACTOR 100 Price
Pricing varies by region and distributor, but these ballpark figures will help you budget.
Condition | Est. Price (USD) | What You Get / Key Factors | Best For |
Brand New (Full Package) | $16,000 – $22,000 | • Latest Ultra model • Full Warranty (1–2 Years) • Includes: Optional Tablet, V-ACTOR Handpiece, & Trolley. | Clinics wanting the full turn-key setup with all accessories. |
Brand New (Base Unit) | $13,500 – $15,500 | • Latest Ultra model • Standard Display (No Tablet) • Excludes: V-ACTOR and Trolley. | Clinics that already have a cart or don't need the vibration tool. |
Demo / Showroom | $11,000 – $14,000 | • Unboxed units used at conferences • Minimal usage • Often includes full warranty. | Bargain hunters who want new quality at a discount. |
Refurbished / Used | $6,000 – $9,000 | • Older units (upgraded/closed clinics) • Caution: Check the Shock Count. | Startups on a tight budget or busy clinics adding a backup unit. |
Storz Medical D-ACTOR: At a Glance
Feature | Details |
Key Hardware | Active-Tip-Control (in-handpiece adjustments), integrated Silent compressor, and V-ACTOR vibration therapy support. |
Clinical Range | Treats chronic tendinopathies (plantar fasciitis, myofascial pain) and aesthetic concerns like cellulite via the FALCON transmitter ecosystem. |
Operations | Oil-free compressor reduces maintenance; high-durability projectiles minimize consumable costs. |
Pros & Cons | (+) High mobility, dual-functionality, ergonomic. (-) Radial pressure only; less peak power than stationary tower units. |
The D-ACTOR 100 ultra is a portable radial shockwave system optimized for multidisciplinary clinics requiring mobile treatment of musculoskeletal tendinopathies and aesthetic indications
Wrapping It Up
The Storz Medical D-ACTOR 100 (MP100 Ultra) proves that high performance doesn’t have to come with a massive price tag. By delivering full clinical intensity in a portable, self-contained design, it offers the best of both worlds for busy practitioners.
Whether your clinic focuses on orthopedic recovery or aesthetic treatments, this compact unit is a versatile powerhouse.
It remains a smart, future-proof investment for anyone looking to expand their services with a reliable machine that is built to last.
FAQ
What is the difference between the Storz MP100 and the MP200?
While both machines offer the same power (up to 5.0 bar), the MP100 is designed for portability (approx. 10.5 kg) and has one handpiece port. The MP200 is a heavier, stationary unit (approx. 23 kg) that features two ports and supports vacuum therapy.
Does the D-ACTOR 100 require a separate air compressor?
No. One of its best features is the built-in silent compressor. This makes the unit self-contained, so you don’t need a noisy external air box or messy hoses cluttering your workspace.
What types of conditions can I treat with this device?
The MP100 is highly versatile. It is effective for orthopedic conditions like chronic tendinopathies (such as plantar fasciitis) and myofascial pain, as well as aesthetic treatments like body contouring and cellulite reduction.
How does the D-ACTOR 100 generate shockwaves?
It uses ballistic pneumatic technology. A built-in compressor uses air to fire a small projectile inside the handpiece. When this projectile hits the transmitter tip, it creates strong kinetic energy waves that travel into the tissue. It works much like a high-precision jackhammer.
How much does the Storz D-ACTOR 100 cost?
Pricing depends on the condition of the unit. A brand-new full package typically ranges from $16,000 to $22,000 USD. Used or refurbished units can often be found for between $6,000 and $9,000 USD.
